AZS Brick is a kind of fused cast zirconia-corundum refractory brick which is short writing of abbreviation that AZS from “A” of Al2O3, “Z” of ZrO2 and “S” of SiO2. Such as No. 33 fused cast zirconia-corundum refractory brick adopts the “AZS-33#” as its abbreviation, No. 36 fused cast zirconia-corundum refractory brick adopts the “AZS-36#” as its abbreviation and No. 41 fused cast zirconia-corundum refractory brick adopts the “AZS-41#” as its abbreviation.

Composition of AZS brick

AZS Brick is a kind of white solid body that made from alumina powder and about 65% ZrO2 and 34% SiO2 with zircon sand inside, and which is poured into mould after being melted in the electric melting furnace. AZS bricks’ petrographic structure is made of eutectoid and glass phase of corundum and zirconium clinopyroxene.

AZS Bricks Supplier

Rongsheng Company is a professional manufacturer of Magnesia Carbon brick in China, with top quality and cheap price, we have gain good reputation worldwide and get good feedback.We focus On Manufacturing all Kinds of refractory bricks for furnace or Kiln application. RS Company Has Professional And Large Refractory Factory In China. If you need AZS brick, also named as zirconia-corundum refractory brick, please feel free to contact with us, we will provide you with the best service and products.

Characteristics of AZS Bricks:

1.Strong glass corrosion resistance and high thermal shack stability.

2.Good wear-resistance,dregs-resistance and alkali corrosion resistance.

3.High-purity raw material, barely no pollution.

4.Top quality, long service time.

Application of AZS Bricks

The AZS bricks are mainly applied for the top and bottom structure of melting chamber.Such as melting tank,the tank wall brick, the paving brick,the forehearths and so on.The high corrosion part shall be AZS 41#, such as the feeding part, the throat,the bubble brick, the furnace weir, the burner block, the tongue brick the discharging part and so on.



Properties

chemical composition

AZS-33

AZS-36

AZS-41

ZrO2

≥33

≥35

≥40

SiO2

≤16.0

≤14

≤13.0

Al2O3

a little

a little

a little

Na2O

≤1.5

≤1.6

≤1.3

Fe2O3+TiO2

≤0.3

≤0.3

≤0.3

Physical Properties

bulk density(g/cm3):

3.5-3.6

3.75

3.90

cold crushing Mpa

350

350

350

thermal expansion coefficient (1000°C)

0.80

0.80

0.80

exudation temp. of glass phase

1400

1400

1400

corrocion resistance  of glass melt(mm/24h)

1.6

1.5

1.3

Density

PT   QX

3.40

3.45

3.55

WS    ZWS

3.60

3.70

3.8

phase composition(%)

baddeleyite

32

35

40

glass phase

21

18

17

α- corundum

47

47

43
